Question

How to Fix Epson Printer Head Alignment Not Working?

Hello, Please let me know that how to fix Epson printer head alignment not working problem. Whenever i am trying to print with Epson printer it cause this printer head alignment not working issue. Give me any solution to fix it.

  •   Mick
  •   3  Ans
  •   Mar 23, 2021
Answer - 1

Fix Epson Printer Head Alignment Not Working

As an Epson printer user, you must have come across an error that appears as absent printer head alignment not working. This issue is caused by jammed paper inside the printhead, slogging due to dust piles, improper installation of the cartridges, bad quality of cartridges, or large and long printing sessions.

All of the mentioned issues can be due to the "Epson printer head alignment not working" error. Some of the problems that are caused by this error are missing or incorrect colours, blurry printouts, horizontal bindings, and issues with vertical alignment. These issues should be resolved for the proper functioning of the Epson printer.

Possible Causes of Epson Print Head Alignment Issues

Epson Print head alignment issues are the most common and you can resolve them effortlessly by seeking professional help. But before that, you must know the probable reasons behind the Epson printer head alignment not working issues.

  • Jammed paper issue inside the print head.
  • Clogging issue or dust piles in your print cartridge.
  • Issues due to improper installation of the cartridge.
  • Issues caused due to the poor quality of the cartridge.
  • After completion of a large printing session.

Keeping in mind these parameters, you can prevent the chances or resolve the printer head alignment issues if already occurred. it should solve your purpose in the first place. Further, if you are still getting issues with the printhead or obtaining undesired printing results, you should search for Epson print in error state services.

What Problems Are Caused Due to Epson Print Head Alignment Errors?

Undoubtedly, alignment issues are complicated to resolve and make your printer purchase decision wrong sometimes. and can make the purchase of your printer useless. If you are one of those who are experiencing any of these discussed problems above, you surely need some expert guidance to resolve the Epson print head alignment issues.

Given below is a list of common issues that require expert solutions to get resolved

  • Problems caused by incorrect or missing colors.
  • Issues due to blurry printouts.
  • Issues caused by horizontal banding.
  • Vertical misalignment issues.

Follow Steps to Overcome Printhead Alignment Errors

Step 1: Horizontal Banding -

  • Run the Print Head Alignment Utility
  • Place the printable side of the paper inside the sheet feeder
  • Run the Head Cleaning Utility to clear the clogged ink nozzles.
  • Reset all the customized settings, and select Text, and Image settings.
  • The other way is to select the Automatic settings under the Mode tab of the Print dialog box.
  • Check out the light status of the ink-out indicator. If it is flashing, then you have to replace the desirable ink cartridge
  • Do not select Minimize Margins and ensure not to select Maximize setting as the Printable Area.
  • Lastly, ensure that the media type selection in the printer software is compatible with the type of media loaded in your printer.

Step 2: Vertical Misalignment or Banding -

  • Put the printable side of the paper into the sheet feeder.
  • Run the Print Head Alignment Utility.
  • Disable (clear) the High-Speed Checkbox in the Advanced dialog box.
  • Now, run the Head Cleaning utility to clear clogging of ink nozzles.
  • Remember the Media Type setting should be in accordance with the type of media loaded in the printer.

Step 3: Recover/Resolve Incorrect or Missing Colors -

If you are noticing some incorrect or missing colors, then change the Ink setting in your printer software to Color. Additionally, adjust the color settings in your application. You can even run the Head Cleaning Utility to clean incorrect colors. Ensure that you are not using ink cartridge beyond its expiry printed over the cartridge package.

Step 4: Resolve Issues Due to Blurry Printouts -

To get rid of blurry printouts you can use the appropriate driver for your printer. Ensure that you use Epson friendly paper and always place your printer on a flat surface. Also, run the Head Cleaning Utility or the Print Head Utility.

Still, if the printhead issues are not resolved, you must search for Epson printers is in an error state for instant solutions.

How to Align the Printhead on Your Epson Printer?

The following useful guide will help you to align the print head on your Epson printer. This guide is applicable for Epson XP-410 head alignment correction. Do not skip out any of these steps for better printing results.

For Windows User :

  • Load plain A4 or letter-size printing paper into the sheet feeder.
  • Now access the printer software.
  • Click on the Print Head Alignment button under the Maintenance tab.
  • Start following the on-screen instructions to align the print head properly.

For Mac OS (8.6 to 9. x) User :

  • Load A4 size plain paper in the sheet feeder.
  • Access the Page Setup dialog box.
  • Click on the Utility icon button and then over the print head alignment button.
  • Further, follow the on-screen instructions to complete aligning the print head of the machine.

For Mac Os (X) User :

  • The steps are the same as that for OS (8.6 to 9.x).
  • Again you have to load A4 size paper in the sheet feeder.
  • Now access the Epson printer Utility in the dialog box.
  • In order to access the accessing printer utility, make printer selection and click OK in the printer list window.
  • Further, click the Printhead Alignment button in the Utility dialog box.
  • Lastly, follow the on-screen instructions which appear on your screen to resolve the alignment error.

Still, if these steps do not help in resetting print head alignment Epson printer, seek some professional assistance. Do keep in mind that you are choosing a reliable print service.

  •   Alex
  •   March 13, 2024
Answer - 2

Fix Epson Printer Head Alignment Not Working:

Noticing unwanted horizontal banding or non-aligned vertical lines may make you worried and frustrated. This may have been caused due to issues related to the printer’s improper head alignment ultimately paving the way for the creation of a complete guide that prescribes ways to fix the Epson printer head alignment not working issue.

Troubleshooting Epson Head Alignment for Windows

Step 1 - In the attempt to fix the Epson printer head alignment not working issue, first ensure that A4 or Letter size papers are loaded in the paper feeder.

Step 2 - Now access the software of your Epson and continue clicking the “Maintenance” tab.

Step 3 - It is time to click the “Print Head Alignment” button followed by adhering to the on-screen instructions to align the Epson’s print head.

The Simple Way to Deal with Improper Print Head Alignment on Your Epson

Step 1 - Here as well you have to make sure that A4 papers or the bunch of Letter-sized papers are properly loaded in the Epson Sheet Feeder.

Step 2 - At this stage access the Print or Page Setup dialog box.

Step 3 - Now click the “Utility” icon and then click the “Print Head Alignment” button going forward.

Step 4 - Continue to follow the on-screen instructions to successfully fix the Epson printer head alignment not working issue by aligning the print head ultimately.

Here is the Aligning Process for Mac OS as Well

Step 1 - Load the lot of A4 papers in the Sheet Feeder.

Step 2 - Access the Epson printer utility’s dialog box to carry on the process of fixing the Epson printer head alignment not working issue.

Step 3 - Here you need to choose the specific printer followed by clicking the “OK” button in the Printer List window.

Step 4 - Don’t forget to click the “Print Head Alignment” button in the utility box provided therein.

Step 5 - Keep following the on-screen instructions and get the print head aligned.

  •   Allan
  •   March 4, 2024
Answer - 3

Fix Epson Printer Head Alignment Not Working:

You can directly adjust the print head and use the control panel on your item when you are unable to run an automated printing adjustment on your paper or if the automated adjustment does not solve the issue. Epson Printer Head Alignment Not Working

Step 1: Roll and cut sheet paper should be loaded into the printer.

Note: Make sure your paper is at least A4 (8.3 x 11.7 inches; 210 x 297 mm).

Step 2: Ensure that the appropriate paper type is chosen.

Reminder: Be sure to make the custom paper settings in before if you're using paper that is readily available commercially.

Step 3: Using the power button is optional.

Step 4: Choose Paper Setting from the menu.

Step 5: Choose the choice for the printer's paper load.

Step 6: Choose Print Head Alignment under Print Adjustments.

Choose from the Following:

  • Each colour is aligned for printing in one direction using Uni-D Alignment (takes 25 to 35 minutes to complete)
  • For printing in both directions, bi-directional alignment aligns each colour (takes 9 to 13 minutes to complete)

Choose Manual, then choose Start. The initial adjustment design is printed by the printer. After each design is printed, load new sheets of paper if you're printing upon cut sheets.

Follow the directions on the LCD screen to choose the optimum outcome for each pattern set once each alignment pattern has been printed. Depending on the size of the paper, many pattern sets may print. If yes, examine every pattern set then take the average of the alteration value.

The estimated value would be 1, for instance, if two pattern sets to print and the best values are 0 and 2 with each set. The adjustment value should be 1. Rounded off towards the closest whole number if the mean result is not an integer.

  • Verify the outcomes once the alignment is complete.
  • Repeat the procedure if the print head still appears to be out of alignment.
  •   Steffan
  •   March 4, 2024
