How to Fix Canon Printer Alignment Problem?

Hi, I have a Canon wireless printer which is 7 months old. I use it for my office paperwork and a few printing requirements here and there. Basically, I am not a heavy user. My printer was working perfectly fine until last night when I realized that it is printing awkwardly. The prints are not aligned. The problem is occurring since last night only, I have tried rebooting and updating the software but that did not help. Can anyone here suggest me anything which might resolve this issue?

  •   Mick
  • lay  2  Ans
  • lay  Dec 15, 2020
Answer - 1

Fix Canon Print Head Alignment Not Working:

Go Through These Steps to Fix Canon Printer Alignment Problem -

(Procedure for performing manual print head alignment)

  1. First of all, you have to open Printer Driver Setup Window.
  2. On the Maintenance tab, you have to click on Custom Settings. By doing this, the Custom Settings dialog box will open.
  3. Now, you have to switch head alignment to manual. Also, click on the checkbox that is next to “Align Head Manually”.
  4. After this, apply the settings. Once the confirmation message occurs, click on OK button.
  5. Again move to Maintenance tab and tap on “Print Head Alignment”. Now “Start Print Head Alignment” dialog box will appear on the screen.
  6. Now, you have to load papers of appropriate size in the Canon printer. Just note one thing, the paper should be of proper size and load into the rear tray.
  7. Now you have to check the pattern that is printed on the paper. In fact, you have to enter the numbers of patterns in the associated boxes with the least amount of streaks. After entering all necessary values, click on the OK button.
  8. Now you have to confirm the displayed message and then click on the OK button.
  9. At last, check the printed pattern. Although it is difficult to choose the best pattern so you have to pick the settings that produce the least noticeable horizontal stripes. If you want to print and check the current setting, open Start Print Head Alignment dialog box and then tap on Print Alignment Value.

Note: In case your printer print double letters then Click Here that how to resolve double letters in a Canon Printer printout.

Hopefully, you understand that how to fix Canon printer alignment problem, In case any kind of issues is disturbing you then without wasting your time, give a reply then we will try to help you.

How to Align Print Head on Canon Printer-

  1. Insert papers into printer’s tray and then press the Maintenance button. To print the alignment sheet for the print head, you have to press “Black” or “Color” copy button.
  2. Now you have to open scanning bed lid and after this, you have to place alignment sheet (face down) on the bed. After placing alignment sheet appropriately, close the scanning bed lid.
  3. Next, press Maintenance > Black copy button to align the printhead. You can discard the alignment sheet after completion.

Note: if your Canon printer is connected but the printer is not responding then Click Here for short out your Canon Printer.

canon print head alignment, how to fix printer alignment canon

  •   Jed
  • lay  March 4, 2024
Answer - 2

Fix Canon Print Head Alignment Not Working:

If your Canon printer has alignment problem then definitely your printer will not print accurately. In fact, your Canon printer can become misaligned if any piece of paper gets stuck inside the machine.

Generally, the printer becomes misaligned when printer finishes a large print job. If you are using Windows operating system then you can use “Printers and Devices Alignment Utility”.

Canon Printer Alignment- For Windows

  1. Go to Start and then tap on “Devices and Printers”.
  2. In next step, you have to press right click on Canon printer icon. From the pop-up menu, you have to choose Printing Preferences.
  3. Next, tap on Services> Align the Print Cartridge icon.
  4. Now your Canon printer will automatically print an alignment test page.

To align the cartridges, you have to follow instructions from the Alignment wizard. When the alignment wizard complete, click on Finish.
Printer Software-

  1. Launch the printer’s software and then choose Maintenance> Tools.
  2. Tap on the Alignment Printer option and then click on the Canon printer Alignment button. Now an alignment page will print.
  3. To complete the alignment process, you have to follow the instructions of alignment wizard. Once alignment process gets complete, click on Finish.

Physical Issues

  1. Check carefully if any paper is stuck inside the Canon printer. This is because struck papers can cause the printer cartridges to improperly align. So, remove all struck papers from your printer to fix the problem completely.
  2. If printer’s cartridges are dirty or clogged then replace them as soon as possible.
  3. You can also install new manufacturer’s cartridges in Canon printer.

Note: If you have Canon MP210 Printer then installed without CD.

If still, you are unable to fix Canon print head alignment not working problem then post your query on Canon Printer forum in the proper way and receive the perfect answer from experts.

canon printer alignment, canon print head alignment, canon print head alignment not working
