How to Fix Canon Printer Carriage Jam Problem?

Hello, Please tell me about how to fix canon printer carriage jam problem. I am facing this problem with Canon printer while printing. I don't know about fixing this issue. Give me any idea.

Share

Solution for Canon Printer Carriage Jam Problem:

If you are a Canon printer user, then there is a high possibility for an unwanted carriage jam error to pop up when you are using it. Canon printer carriage jam issue is a very annoying kind of error and you can only get rid of it when you know the correct way to solve your problem.

In comparison to other printing devices, Canon printer has been proved as one of the best printers for both home as well as office use. Canon printers are ideal printing devices that helps you in taking out crisp and sleek printouts. But you may also come across issues like paper jams, ink cartridges, and quality.

If you own a printing device, then you must be well aware of the printing process. The printer holds the ink cartridge and slides forwards and backwards and then transfers ink on the sheet. You should also know that sometimes the paper jam errors also lead to the carriage jam errors.

It generally happens when you print on thick paper. You must also be having good knowledge about the carriage stalls and you will also get to listen to a grinding sound when the printer starts moving on the carriage.

The carriage jam issue arises when the actuator arm gets stuck, which actually stops the carriage from moving. In order to get rid of this problem, then below are some of the steps that you need to follow:

Step to Remove Canon Printer Carriage Jam Problem?

Step 1 : First of all to solve canon printer carriage jam problem, remove the power wire from the device and then open the cover of your printer for disclosing the carriage assembly.

Step 2 : Now, in order to remove the tray just squeeze both the levers that are below the paper tray.

Step 3 : After that to solve canon printer carriage jam problem, you will need to move the carriage assembly from your printer’s left side to the center where you can easily have an access to it. If it does not slide, then in that case you must move forward with the next step.

Step 4 : Then, push the black bars downwards which are on top of the rollers. After that, you need to release it so that it springs back. Then, you need to bring the carriage assembly back to the right. If now it slides, then you need to move to the next step.

Step 5 : After that to solve canon printer carriage jam problem, in the tray compartment locate a flat-shaped component beneath the rollers. You will see that this component is parallel to the base of your printer. If it points upwards, then you need to push it down.

Step 6 : After that, move the carriage assembly in the right direction and then place each of the parts in the correct way.

Step 7 : Then to solve canon printer carriage jam problem, lift the actuator arm that is placed on to of the gray or white geared assembly on the left side. Once you release it, then you need to restore it in the right position.

Step 8 : Now that you have placed the paper tray back in the device, then connect the power cord and turn on your printer again.

Step 9 : Press and hold resume and then shut the cover of your printer.
