Where is the WPS PIN on My Kodak Printer?

Hello, Please let me know that Where is the WPS PIN on my Kodak printer. I am facing some issues while finding it. Help me.

  •   Mick
  • lay  1  Ans
  • lay  2 years ago
Answer - 1

WPS PIN on my Kodak printer:

If you are trying to find WPS PIN but you didn’t find it. In this post, you will find the process to find WPS PIN on Kodak printer.

To Connecting Your Kodak Printer to WiFi-

Note: Wi-Fi Direct may be a feature that's only on the ESP 3.2s All-in-One Printer (printer availability varies by country).

Your ESP 3.2s All-in-One Printer is often found out to host a Wi-Fi Direct network so you'll connect mobile devices and computers* without employing a router. Through Wi-Fi Direct, your printer works as an access point so you can:

  • Use your mobile device to print from the app KODAK Pic Flick.
  • Print or scan from your computer with WINDOWS OS or MAC OS (with the required drivers installed).
  • Access the web Printer, Management Tool.

To get the best results, use your device within 5 m / 16.4 ft of your printer. Confirm that there are not any obstructions between your device and printer.

Wi-Fi Direct doesn't have Internet access. For full printer functionality, connect your printer to your wireless network (see Connecting to a wireless network). Your printers are often connected to your wireless network and have Wi-Fi Direct enabled at an equivalent time.

Enabling and Using Wi-Fi Direct

Step 1: Click on Home Icon.

Step 2: Tap , then touch Network Settings.

Step 3: Tap , then touch Manage Wi-Fi Direct.

Step 4: Tap activate Wi-Fi Direct.

Step 5: Write down the Wi-Fi Direct information displayed on the control panel:

  • Network Name (SSID)
  • Security String

Step 6: Tap OK.

Step 7: Connect your device or computer to the network (SSID), then enter the safety string. Use the knowledge that you simply recorded in step 5.

Step 8: To print via a mobile device, take a look at the Mobile Printing.

Step 9: To print via a computer, choose your wireless printer.

If you are not seeing "+xxxx" after your printer name, you have to download the printer drivers; follow the instructions below for your OS .

On a computer with WINDOWS OS:

  • Tap Start > All Programs > Kodak > Kodak Printer Setup Utility.
  • Select No, my printer isn't listed, then click Next.
  • From the drop-down list, choose your printer, after that tap Next.
  • When your printer is detected, driver installation begins.
  • When the driver installation is complete, click Done.

On a computer with MAC OS:

  • Select Apple > System Preferences.
  • Inside Hardware, choose Print & Fax or Print & Scan.
  • Click + within the panel.
  • Select your printer from the list.
  • Click Add, if required.

Step 10: For more information on printing, see Printing. For more information on scanning, see Scanning.

Connecting and through Wi-Fi Direct for a Mobile Device or Computer via WPS

Step 1: Click on the Home icon.

Step 2: Tap on the left arrow icon, after that touch Network Settings.

Step 3: Tap on the drop-down arrow icon, after that tap on Manage Wi-Fi Direct.

Step 4: Tap Connect a tool Using WPS.

Note: Before you create a variety on the printer, confirm you know:

  • The location of the push on your mobile device or computer — it'll be a button on your device, or a virtual button within the device software.
  • where to get a WPS Pin on Kodak printer or mobile device and computer.

Step 5: Select one among these methods to attach your device:

Push Button Configuration

Note: You will have two minutes to click the WPS button.

  • Tap push Configuration.
  • On your mobile device or computer, tap the WPS button.
  • Tap OK on your printer instrument panel.

Enter a WPS Pin-

  • Touch Enter WPS Pin
  • From your mobile device or computer, navigate the Pinscreen and generate a WPS Pin.
  • Enter the WPS Pin on Kodak printer instrument panel, after that tap OK.

Step 6: To print via a mobile device, see Mobile Printing.

Step 7: To print or scan from a computer:

  • Go to (for ESP 3.2 Printers) or (for ESP 3.2s Printers).
  • Select the All-in-One Printer Software for your OS.
  • Follow the on-screen instructions to put in the software. (The printer and scanner drivers are installed once you install the software.)
  • To print, see Printing. To scan, see Scanning.

Viewing your Wi-Fi Direct Network Configuration

Step 1: Click on the home icon.

Step 2: Tap on the left arrow icon, after that tap on the Network Settings.

Step 3: Tap on the drop-down arrow icon, after that tap on the Manage Wi-Fi Direct.

Step 4: Touch View Wi-Fi Direct Configuration. The Wi-Fi Direct settings appear on the LCD. To scroll and review the settings, touch.

  • Wi-Fi Direct
  • SSID
  • Security String
  • IP Address
  • Subnet Mask
  • Channel
  • Region
  • MAC address
  • No. of devices connected

Step 5: When you are done, touch OK.
