How to Fix Samsung C1860 Laser Printer Error a1-4111?

Hello, Please let me know that how to fix Samsung C1860 laser printer error A1-4111. I am facing some issue while printing some error with Samsung printer. Help me.

  • Ronny
  • 1 Answer
  • February 14, 2024
Answer - 1

Fix Samsung C1860 Error A1-4111:

Are you finding samsung c1860 error a1-4111 on the display screen? Depending upon the printer model, you can search for the fix methods. Most of the fixes available are not helpful, but this will surely work to fix the problem.

Instructions to Fix Samsung Printer Error A1-4111 -

Phase 1: Remove the Right Side Panel

Step 1: Before starting the process to fix Samsung C1860 error A1-4111, turn off the power firstly. You can find the power switch next to the power cord so that you can simply disconnect the power cord.

Step 2: Remove or disconnect any data cables (if connected) since you might be spinning it all around which would turn complicated.

Step 3: Most of the printers have the 5 screws that need to be removed first. The number of screws will vary model to model.

Step 4: Facing the front side, you can open the large lower front cover. Thereafter, remove the three screws on the front right side of the printer.

Step 5: Next, turn to the backside and open the back cover of the printer. Also, remove the two screws on the left side. Please remember the different screws and their respective positions on the panel.

Step 6: Lastly, slide the right side cover towards the back end. Note that it should come away easily and swiftly so you can set it aside.

Phase 2: Fix the Solenoid

The Samsung Xpress c1860fw error a1-4111 problem is major with the small blue solenoid at the upper left corner. Subsequently, the pad slips or falls off due to which the printer gets unhappy and problematic.

Step 1: Initially, remove the retaining screws and pull it out a bit to start the work mode.

Step 2: In case, if yours is missing then you can look around for it. As the stickiness goes away, a few layers of masking tape cut in small square pieces can fix Samsung printer error A1-4111 problem.

Step 3: In the current case, the small foam pad had just slipped. So, you can just carefully lift it using an X-acto knife. Further, reposition it and do make sure it was stuck well right under the tab only.

Phase 3: Test and Reassemble the Unit

In the third phase to fix Samsung C1860 error A1-4111 problem, you need to reinstall the solenoid.

Step 1: If you wish not to touch any open electronics, then plug in the power cord to source and check if the error goes away or not. Carefully, watch the motors and solenoid to verify that they spin correctly and click on power-up sequencing.

Step 2: Next, you have to remove the power cord so that you can put the side panel back on.

Step 3: In the last step, start reversing the steps of disassembly. Just make sure to place the different screws into the correct hole. You can see that the tiny screw goes in the lower position in the back of my model printer.

Step 4: So, finally, you can plug in and enjoy.

Hope the guide works to resolve Samsung printer error A1-4111.
